Aircraft Terminal Block - To calculate the overall star rating and percentage breakdown by star, we don't use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon.
It also analyzed reviews to verify trustworthiness. Toll Free: 877-477-7823 Customer Service: 800-861-3192 Fax: 800-329-3020 Terminal blocks are commonly used in the electrical systems of airplanes. They consist of block-shaped connectors that support multiple wires or cables.
Aircraft Terminal Block
Rather than using a twist-cap connector, for instance, you can connect two wires with a terminal block. Below are five facts about terminal blocks. You don't have to crimp wires or cables when using a terminal block.
No Crimping Required
While there are exceptions, most terminal blocks do not require crimping. To use them, simply insert the wires or cables into the open ports on the sides. You can then clamp the exposed ends of the wires or cables by tightening the respective screws over them.
Terminal blocks offer a convenient connecting solution for wires and cables. For standard terminal blocks, you need to tighten a screw over each wire or cable. For push-fit terminal blocks, you can insert wires or screws directly into the block, at which point they will clamp in place.
Many electricians prefer terminal blocks over traditional connectors because they offer organization. Terminal blocks don't just connect wires or cables; they organize them. When connected with terminal blocks, wires and cables are neatly organized. This makes them easy to identify and manage in the future.
Some electricians may even color-code the top of a terminal block to label the connected wires or cables. Please note, Aircraft Spruce's personnel are not certified aircraft mechanics and can only provide general support and ideas, which should not be relied upon or implemented in lieu of consulting an A&P or other qualified technician.
In Conclusion
Aircraft Spruce assumes no responsibility or liability for any issue or problem which may arise from any repair, modification or other work done from this knowledge base. Any product eligibility information provided here is based on general application guides and we recommend always referring to your specific aircraft parts manual, the parts manufacturer or consulting with a qualified mechanic.
Terminal blocks are easy to install. As previously mentioned, they do not require crimping. Therefore, you don't need a crimping tool to install terminal blocks. You just need a screwdriver as well as a wire stripper or utility knife.
The screwdriver will allow you to clamp the wires or cables in the terminal block, whereas the wire stripper or utility knife will allow you to cut away the protective outer layer on the ends. In addition to barrier, another alternative type of terminal block is push-fit.
Also known as push-in terminal blocks, they live up to their namesake by requiring nothing more than a "push" to use. You can use a push-fit terminal block by pushing the wires or cable into it.
Offers Organization
If you push a wire or cable into a push-fit terminal block, it will clamp down. When shopping for terminal blocks, you may come across barrier terminal blocks. Barrier terminal blocks are still used to connect multiple wires or cables — just like all terminal blocks.
The difference is that barrier terminal blocks feature ring terminals to further protect the wire or cables from loosening.
